CUDY 2-IN-1 SMB Router / AP Controller
CUDY 2-IN-1 SMB Router / AP Controller
The Cudy C200P router functions as a versatile 2-in-1 network solution that combines the functions of a gigabit VPN router and a hardware access point controller. The device is designed for deployment in small and medium-sized businesses (SMB), where it enables centralized management of up to 200 Cuda access points in dedicated controller mode through a single interface. The durable metal chassis is ready for tabletop or wall mounting and provides the passive cooling necessary for continuous operation in harsh environments.
Key Features of the CUDY 2-IN-1 SMB Router / AP Controller
- A 2-in-1 device combining a gigabit VPN router and controller to manage up to 200 access points
- Four gigabit LAN ports with 802.3at/af PoE+ power support (PoE budget up to 55 W, 60 W power adapter)
- Integrated support for WireGuard VPN protocols, OpenVPN, IPsec, Zerotier, PPTP, L2TP in server and client mode
- Advanced networking features including Cudy Mesh, Captive Portal, Multi-SSID and traffic segmentation tools
- Hardware features include an 880 MHz dual-core processor and 256 MB of DDR3 RAM
- Durable metal design with USB 3.0 port and flexible desktop or wall mounting
Network performance and management
The smooth operation of the system is ensured by a dual-core processor with a frequency of 880 MHz, which is supported by 256 MB of DDR3 operating memory and 16 MB of flash memory. This hardware configuration supports advanced networking features including IPv6, QoS for bandwidth management, and SPI firewall. The device excels in its broad support of VPN protocols, like WireGuard, OpenVPN, IPsec, Zerotier, PPTP and L2TP, while in WireGuard server mode it reaches throughput up to 213 Mbps. For network segmentation and user management, Captive Portal features with customizable login page and Multi-SSID are available to separate the traffic of each user group. In addition, network administrators will appreciate the features for centralized maintenance of multiple devices and scheduling of automatic firmware updates that make it easier to run large installations.
Connectivity and PoE+ power
The physical interface consists of five gigabit RJ-45 ports, divided into 1× WAN and 4× LAN. Ports no. 2 to 5 have PoE+ support according to IEEE 802.3at/af standard with a maximum output of 30 W per port. Total PoE power budget is 55W, allowing direct power to connected access points or IP cameras without the need for additional adapters. The equipment is complemented by 1× USB 3.0 interface, which can be used for network data sharing via the Samba server function. The device can be powered using the included 54V DC adapter or directly from PoE-in (802.3at/af or passive 24/48V), making it easy to install in a rack without additional outlets.
Technical specifications
Interface: 5× Gigabit RJ45 (1× WAN, 4× LAN PoE+)
PoE: 4× PoE+ 802.3af/at, up to 30 W per port, PoE budget 55 W
VPN support: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP
Hardware: 880 MHz Dual-Core CPU, 256 MB DDR3 RAM, 16 MB flash
Functions: Gigabit VPN router, AP Controller, Cudy Mesh
Specifications
Type
Processor
Standards and protocols
Management and security
Functions
Ports
Number of LAN ports
Speed
PoE properties
Features
Storage
Dimensions
Colour
Material
Operating temperature
Package contents
Power outlet type
Specifications can be changed without notice. Images are for illustrative purposes only.
